If the search rule file is not locked, the link creates a section at the end of the file and a list of all of the files that were found and linked to the search rule file. It then uses the rules in the file to find the other files and to create references from the search rule file to them. The AutoCAD Plant 3D link creates a reference from the project file to the search rule file with the type AcadPnID Custom Part. Navigate to and select the MeridianLinkSearchRules.txt file that you created in the vault. The Select documents description file dialog box appears. In the Meridian ribbon, click Attach Custom. Open any drawing to enable the Accruent ribbon. In AutoCAD Plant 3D Project Manager, open the project.xml file from the Meridian vault. Import the project with the Meridian Assembly Import Wizard as described in Import Assemblies.Ĭreate the file MeridianLinkSearchRules.txt in the project folder of the vault as described in Configuring project file synchronization in the Accruent Meridian Enterprise Configuration Guide.

To configure the AutoCAD Plant 3D link drawing tag synchronization, consult a system administrator about the settings in the AssetSettings section of the AutoCAD link in the vault configuration that are described in the Meridian Asset Management Module Administrator's Guide. To enable the AutoCAD Plant 3D link tag functionality, consult a system administrator about setting the AcadPnIDConfig registry setting described in the Meridian Asset Management Module Administrator's Guide.

It provides functionality for linking AutoCAD Plant 3D drawing tags (not just the standard Asset Management Module tags) to Meridian documents and managing synchronization states. If AutoCAD Plant 3D is used with the Meridian Asset Management Module, the AutoCAD Plant 3D link that is included with that module should be used instead of the basic AutoCAD Plant 3D link. For full functionality, property synchronization should be configured as described in Configuring the AutoCAD Plant 3D link in the Accruent Meridian Enterprise Configuration Guide.
